Hardware Resources: Template - 36" x 36" Wall Cabinet, 2 Doors, 2 Shelves

Hardware Resources: Template - 36" x 36" Wall Cabinet, 2 Doors, 2 Shelves

$469.06
$698.00 $469.06
Sale Sold out

36" x 36" Wall Cabinet, 2 Doors, 2 Shelves - Unfinished

Description: The Catalina design features a full-overlay Shaker door style with 5-piece drawer front. This cabinet showcases a Polar White painted exterior finish with UV natural birch interior, accenting a modern design. All NorthPoint Cabinetry boasts the luxury of solid wood construction with a simple dovetail assembly method.  The Premier Collection comes loaded with soft-close hinges and undermount slides. This cabinet includes a 5-year limited lifetime warranty.

📏 STOP GUESSING, START MEASURING

Calculate your configuration in seconds.

FEATURES
Framed cabinet with full-overlay doors and drawers
5-Piece Shaker HDF Door/Drawer
1/2" Plywood Box Construction
UV Natural Birch Interior
Concealed 6-Way Adjustable Soft-close Hinges
Matching Painted Exterior End Panels
NOTES
Full Carton Count  1
Inner Carton Count  1


Details
Item Number W3636-CUF
Number of Hinges 4
Assembled No
Closing Soft-close
Door Style Catalina
CA (CARB); Title IV compliant Yes
Cabinet Box Construction Dovetail / Pocket Screw Assembly
Drawer Front Construction 5-Piece Cope-and-Stick
Interior Cabinet Depth (in.) 10-1/4"
Panel Style Flat Panel
Trimmable No
Door Material Birch
Face Frame Material 1-1/2" W x 3/4" T Solid Birch
Interior Finish UV Coated Natural Birch
Finished End Panels No
Cabinet Box Material 1/2" Veneered Plywood
Cabinet Type Wall Cabinet
Cabinet Sub-Type Wall Cabinet Double Door
ADA No
Overlay Full Overlay
Sold By Each
Brand NorthPoint Cabinetry
Number of Doors 2
Finish Unfinished
Number of Drawers 0
Exterior Finish Type Unfinished
Number of Shelves 2
Center to Center ? 3/8"
Overall Length 12 1/4"
Width 36"
Depth 12"
Material Wood
Certification ANSI
Installation Screw
Warranty Period 5 year
